TENDA N301
Router
₹1499.00₹999.00
The N301 Wireless N300 Easy Setup Router is designed to setup more easily for the home user. It complies with IEEE802.11n, delivers wireless speeds of up to 300 Mbps, making it perfect for everyday web activities like e-mail, chatting, streaming videos, online gaming and more. The N301 can also work as a client router to connect ISP network wirelessly or uplink AP to share the Internet to every corner,elimating the dead point.
Hardware
Standard&Protocol
IEEE802.3, IEEE802.3u
CPU
400MHz
RAM
8MB
Interfaces
1*10/100Mbps WAN port
3*10/100Mbps LAN portsAntenna
2*5dBi external antennas
Button
1* Reset/WPS button
Power
Input：AC 110-240V—50/60Hz
Output：DC 9V 0.6ALED Indicator
SYS、WLAN 、LAN(1-3) 、 WAN
Dimensions
127.4*90.5*26mm
Wireless
Wireless Standard
IEEE 802.11b/g/n 2.4GHz
Data Rate
300Mbps
Frequency
2.4GHz
Transmission Power
CE:<20dBm
Basic Features
WiFi On/Off
Wireless Security
WPA/WPA2, WPA-PSK/WPA2-PSK
Software
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)Network Protocol
IPv4
Operating Mode
Wireless Router Mode
Universal Repeater Mode
WISP Mode
AP ModeParental Control
Client Filter
Time LimitDHCP
DHCP Server
DHCP Client List
DHCP ReservationVirtual Server
Port Forwarding
DMZ Host
UPnPDDNS
no-ip,DynDNS,Oray
VPN
IPsec pass through
PPTP pass through
L2TP pass throughSpecial Features
PPPoE Username/password Clone
Smart WiFi ScheduleOther Function
Bandwidth Control
MAC Clone
System Log
Backup & Restore configurations
Firmware upgradeable via browserOthers
Temperature
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.Humidity
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.Certification
CE/FCC/RoHS
Package Contents
Wireles Router*1
Power Adapter 1
Install Guide1
Ethernet Cable*1
